    Large Capacity Mud Vertical Cutting Dryer 55kw For Oil Mud Seperation

    Ask Lasest Price
    Brand Name : TR Solids Control
    Model Number : TRCD930B-VFD
    Certification : API Certificate, ISO Certificate
    Price : Negotiable
    Payment Terms : T/T, L/C, D/A, D/P, Western Union
    Supply Ability : 200 Sets Per Month
    Delivery Time : Within 30 days after deposit
    • Product Details
    • Company Profile

    Large Capacity Mud Vertical Cutting Dryer 55kw For Oil Mud Seperation

    Large Capacity Mud Vertical Cutting Dryer 55kw For Oil Mud Seperation

    Main Introduction

    Drilling vertical cutting dryer is a very important solids control equipment in drilling waste management system. It can deal with large numbers of waste sediment quickly and efficiently, and reduce oil and water content from the cuttings. After treatment, the oil content (OOC) of cuttings can be below 5%. They conform to the international drilling fluid cuttings discharge standard, and meet the increasingly stringent environmental protection needs.

    Generally vertical cutting dryer can recycle a large proportion of synthetic slurry and oil-based mud, reducing waste emissions effectively. Meanwhile it improves the use of waste. TRCD series vertical cutting dryer can recover the oil cuttings in the composition, and processing capacity can arrive 30-50 tons per hour, oil content of cuttings after treatment is generally less than 3%.

    Mud vertical cutting dryer is a kind of drying machine for treating slurry in oilfield. It can be called vertical centrifuge from its structure. It is characterized by advanced design, efficient treatment and long service time. Vertical cutting dryer belongs to environmental equipment among oilfield mud solids control equipment. TR Solids Control can supply two kinds of vertical cutting dryer--fixed frequency & variable frequency.

    Application

    Vertical cutting dryer is mainly used in Coal Bed Gas Solids Control System, Oil Sludge Dewatering Systems, Oil and Gas Drilling, Drilling Waste Management, Trenchless HDD & Tunnelling, Oil Mud Seperation, Bored Pile.

    Advantages of TRCD Series Vertical Cutting Dryer

    • Rotary speed up to 900rpm,separate cutting in liquid effectively;
    • Discharge scraper made of high chromium cast iron,long service life;
    • High-pressure air knife effectively prevents the basket block;
    • Replaceable selection parts meet the machine balance;
    • Separate oil cooling system effectively meets the requirements of high temperature environment.

    Technical Data of TRCD Series Vertical Cutting Dryer


    ModelTRCD930CTRCD930B-VFD
    Capacity(T/h)30-50T/h
    Basket Max.Diameter930mm
    Basket Gap0.25-0.5mm
    Rotary Speed900 r/min0-900 r/min
    Air knife Air Inlet Pressure0.69Mpa
    Air Tool Air Supply1.8m3/min
    Fuel Tank Volume60L
    Main Motor Power(Kw)55Kw
    Oil Pump Power(Kw)0.55Kw
    Weight5900kg6000kg
    Dimension2750*2130*1800mm




    Competitive Advantages


    1. We offer high quality products at competitive price.
    2. S
    hortest delivery time.
    3. Flexible payment terms.

    4. Timely after-sale service.
    5. Most of our equipment can be replaceable with international brands.
    6. Our products have been exported to Argentina, Egypt, US, Australia, Romania, Pakistan, Dubai, Abu Dhabi, Iran, India, Indonesia, Vietnam, Malaysia and many other countries.


    Company Tenet

    Customer's satisfaction is the highest pursuit of TR Solids Control.

    http://www.trsolidscontrol.com/
