    300-600kg/H Mud Treatment System Environmental Protection Equipment

    Ask Lasest Price
    Brand Name : TR Solids Control
    Model Number : TRWNT-20
    Certification : API,ISO
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union
    Supply Ability : 200 Set / Month
    Delivery Time : 35 days after receiving 30% deposit
    • Product Details
    • Company Profile

    300-600kg/H Mud Treatment System Environmental Protection Equipment

    Sludge Dewatering System


    ModelTRWNT-20
    Oven dry sludge capacity300~600kg/h
    Solid content in sludge10000~20000mg/L
    Sludge capacity18~24 m3/h
    Clear liquid solid content0.03%
    Inlet ludge water content75~80%
    Outlet Sludge water contentLess than 30%
    Electricity consumption4.4kw/h
    Flushing water consumption80L/h
    Addition Rate of Polymer FlocculantDS ~0.8%
    Maintaining management frequency5min/day
    Water supply pressure0.1~0.2MPa
    Net weight3500kg
    Operating weight4550kg

    Sludge Dewatering System


    Setting environment


    Temperature Scope of Application-10℃ ~ +40℃ (No ice.)
    Applicable range of humidityMax. 90%RH (No condensation)
    HeightBelow altitude 1000m
    Supply voltageThree-phase 380V 50Hz
    Water supply pressure0.1~0.2MPa

    ※ This Sludge Dewatering System belongs to indoor specifications. Please set it indoors.

    ※ Please set it up according to the specifications and drawings.



    TRWNT-20 Technical Parameter
    NameSludge dewaterer with laminated screw
    ModelTRWNT-20
    Dewater treatment typeSpiral Propulsion Extrusion
    Oven dry sludge capacity300~600 Kg∕h
    SizeL5200×W2100×H2100 mm
    Power4.4kw
    Main Equipment ConfigurationItemSpecification parameter
    Screw bodyDiameter * lengthDN400mmx2700mm
    Number3
    Texture of materialSS304
    Supporting plateTexture of material:SS304
    Control modeThe main body of each group of snails can be opened or stopped independently.
    Assembly typeSubsection design of main body, convenient for later maintenance, double-deck design of support plate, ensure stable operation of equipment
    Helix axisNumber3
    Texture of materialSS304
    Treatment processIntegral finishing after welding, blade strengthened with alloy tungsten carbide
    Hardness1100HV
    Flocculation mixing tankSize900 x 900 x 1500 mm
    Number1 set
    Texture of materialSS304
    CapacityAbout 950[L]
    MixerQuantity:1 Material:SS304
    Sewage inletDN100 flange(JB/T81-94,PN1.0MPa)
    overflow port¢100 pvc
    Dosing port¢25 pvc
    Vent¢65 SS304
    Driving motorPower1.1kw
    Protection levelIP54
    Insulation gradeF
    Quantity3
    Speed1.96-4.9r/min
    Reduction ratio286.4
    Mixing MotorPower1.11kw
    Protection levelIP54
    Insulation gradeF
    Quantity1
    Speed25r/min
    Reduction ratio54.7
    Flushing deviceTypeTapered water column
    Pressure0.2MPa
    Flushing water intake¢25 pvc
    InjectorMaterial: Engineering Plastics
    Spray pipeMaterial:SS304,Size:¢25
    Solenoid valvePipe diameter¢25
    Quantity1
    Texture of materialBrass

    Diameter parameters of each pipe


    Sludge Conveyor inletDN100
    Pharmaceutical liquid delivery port¢25
    Filtrate outletDN80
    Water supply outlet¢25
    Return flow¢100
    Mixed flocculation tank emptying¢63
