    Onshore Oil Drilling Linear Motion Shale Shaker 6mm Double Amplitude

    Ask Lasest Price
    Brand Name : TR Solids Control
    Model Number : TRZS585
    Certification : API certificate, ISO9001 certificate
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union
    Supply Ability : 100 Sets / Month
    Delivery Time : Within 15 days after deposit
    • Product Details
    • Company Profile

    Onshore Oil Drilling Linear Motion Shale Shaker 6mm Double Amplitude

    Onshore Oil Drilling Linear Motion Shale Shaker 6mm Double Amplitude


    Main Introduction


    Mud shale shaker is the first phase solids control equipment in oil drilling solid control system. It's the important equipment in mud recycling system as well. Generally, shale shaker is divided into single shale shaker, duplex shale shaker and triple shale shaker. TR Solids Control can provide shale shaker in different treatment capacity with customized service as per clients’requirement.


    As the strict requirements of national environmental protection, some drilling companies begin to use drilling mud purification system. A drilling company in China improves their mud purification process firstly. After using TR shale shaker, it reduces the amount of mud transportation to the outside place. Besides, our shakers make them reduce the mud weight quickly and effectively, thus reducing the risk of drilling struck. For geothermal drilling, mud shale shaker reduces demand for drilling mud materials effectively, and reduces drilling cost.


    Advantages of our drilling shale shaker

    1. Schneider or Siemens electrical components.
    2. Martin or OLI vibration motor.
    3. Vibration strength is 7.5G, adjustable.
    4. Hopper type feed mode reduces feed speed.
    5. Overall heat treatment, long time work.
    6. Screen box angle is mechanical and adjustable.
    7. Wedge-type compaction device facilitates fast replacement of screen.

    Technical Specification of TR Shale Shaker


    (Model)TRPS703TRPS585-4TRZS703TRZS585
    Vibration MotionBalanced Elliptical MotionLinear Motion
    Treatment Capacity130m³/h140m³/h120m³/h130m³/h
    Motor Power1.94+1.0kw1.94+1.0kw1.5KW×21.72KW×2
    Screen Specs.(700×1250mm)×3(585×1165mm)×4(700×1250mm)×3(585×1165mm)×4
    Screen Area2.6m²2.7m²2.6m²2.7m²
    Vibration Strength≤7.1G≤7.1G≤7.1G≤7.1G
    Double Amplitude7mm7mm6mm6mm
    Deck Adjustment-1°~+5°-1°~+5°-1°~+5°-1°~+5°
    Ex StandardExdIIBt4 / IECEX / A-TEX
    Weight1630kg1618kg1620kg1600kg
    Dimension2770×1785×1690mm2966×1600×1280mm2770×1785×1690mm2966×1600×1280mm
    RemarkAbove data are tested from the drilling mud with viscosity 45s,and specific gravity 1.2g/cm3.


    Competitive Advantages


    1. We offer high quality products at competitive price.
    2. Shortest delivery time.
    3. Flexible payment terms.
    4. Timely after-sale service.
    5. Most of our equipment can be replaceable with international brands.
    6. Our products have been exported to Argentina, Egypt, US, Australia, Romania, Pakistan, Dubai, Abu Dhabi, Iran, India, Indonesia, Vietnam, Malaysia and many other countries.


    Company Tenet
    Customer's satisfaction is the highest pursuit of TR Solids Control.
