    Drilling Mud Solids Control Equipment Shale Shaker 2.6 M2 Screen Area Api Certificate

    Ask Lasest Price
    Brand Name : TR Solids Control
    Model Number : TRZS703
    Certification : API certificate, ISO9001 certificate
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union
    Supply Ability : 100 Sets / Month
    Delivery Time : Within 15 days after deposit
    • Product Details
    • Company Profile

    Drilling Mud Solids Control Equipment Shale Shaker 2.6 M2 Screen Area Api Certificate

    Drilling Mud Fluids Solids Control Shale Shaker , Chinese Shale Shaker Supplier​


    Main Introduction


    Shale shaker for solids control are devices that remove drill cuttings from the drilling fluid while circulating and drilling. There are many different designs and research into the best design is constantly ongoing since solids control is vital in keeping down costs associated with the drilling fluid. The basic design consists of large, flat sheets of wire mesh screens or sieves of various mesh sizes that shakes or vibrates the drill cuttings, commonly shale shaker, across and off of the screens as the drilling fluid flows through them and back into the drilling fluids processing system, often called a mud system. This separates the drill cuttings, often called solids, from the drilling fluid so that it can be re-circulated back down the well bore. In oilfield industry, linear motion shale shaker are widely used for drilling mud solids control of oil gas well drilling for rig.


    TR Solids Control can manufacture balanced elliptical shale shaker, high quality liner shale shaker, and drying shale shaker. We could meet customers' variable requirements. Clients feedback proves the advantages of our shale shaker in the international market. Welcome to contact with us for more details.


    Main Features of Our Mud Shale Shaker:

    1. Vibration strength is 7.5G, adjustable.
    2. Hopper type feed mode reduces feed speed.
    3. Overall heat treatment, long time work.
    4. Martin or OLI vibration motor.
    5. Schneider or Siemens electrical components.
    6. Wedge-type compaction device facilitates fast replacement of screen.
    7. Screen box angle is mechanical and adjustable.

    Technical Data of TRPS/TRZS Shale Shaker


    ModelTRPS703TRPS585-4TRZS703TRZS585
    Vibration MotionBalanced Elliptical MotionLinear Motion
    Treatment Capacity130m³/h140m³/h120m³/h130m³/h
    Motor Power1.94+1.0kw1.94+1.0kw1.5KW×21.72KW×2
    Screen Specs.(700×1250mm)×3(585×1165mm)×4(700×1250mm)×3(585×1165mm)×4
    Screen Area2.6m²2.7m²2.6m²2.7m²
    Vibration Strength≤7.1G≤7.1G≤7.1G≤7.1G
    Double Amplitude7mm7mm6mm6mm
    Deck Adjustment-1°~+5°-1°~+5°-1°~+5°-1°~+5°
    Ex StandardExdIIBt4 / IECEX / A-TEX
    Weight1630kg1618kg1620kg1600kg
    Dimension2770×1785×1690mm2966×1600×1280mm2770×1785×1690mm2966×1600×1280mm
    RemarkAbove data are tested from the drilling mud with viscosity 45s,and specific gravity 1.2g/cm3.


    Competitive Advantages


    1. We offer high quality products at competitive price.
    2. Shortest delivery time.
    3. Flexible payment terms.
    4. Timely after-sale service.
    5. Most of our equipment can be replaceable with international brands.
    6. Our products have been exported to Argentina, Egypt, US, Australia, Romania, Pakistan, Dubai, Abu Dhabi, Iran, India, Indonesia, Vietnam, Malaysia and many other countries.


    Company Tenet


    Customer's satisfaction is the highest pursuit of TR Solids Control.
