Simple Structure Mud Shaker Solids Control System 1600kg Weight Reliable Performance

Xi'an TianRui Petroleum Machinery Equipment Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap Simple Structure Mud Shaker Solids Control System 1600kg Weight Reliable Performance from wholesalers

    Buy cheap Simple Structure Mud Shaker Solids Control System 1600kg Weight Reliable Performance from wholesalers
    • Buy cheap Simple Structure Mud Shaker Solids Control System 1600kg Weight Reliable Performance from wholesalers
    • Buy cheap Simple Structure Mud Shaker Solids Control System 1600kg Weight Reliable Performance from wholesalers
    • Buy cheap Simple Structure Mud Shaker Solids Control System 1600kg Weight Reliable Performance from wholesalers

    Simple Structure Mud Shaker Solids Control System 1600kg Weight Reliable Performance

    Ask Lasest Price
    Brand Name : TR Solids Control
    Model Number : TRZS585
    Certification : API certificate, ISO9001 certificate
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union
    Supply Ability : 30 Sets / Month
    Delivery Time : Within 10 days after deposit
    • Product Details
    • Company Profile

    Simple Structure Mud Shaker Solids Control System 1600kg Weight Reliable Performance

    Drilling Mud Fluids Solid Control Shale Shaker / Linear Motion Drilling Shale Shaker


    Introduction


    Drilling fluid shale shaker is the primary solids control equipment in the drilling fluid solids control system. The shale shaker sreens the drilling fluid with great amount cuttings, separates the large-size solid particles, and sends the drilling fluid to the next seperating equipments. Our shale shaker has the advantages of simple structure,reliable performance,large disposal capacity,long service life,and simple maintenance.


    TR shale shaker absorbed advanced tech at home and abroad, complete series shale shaker can meet customers’variable demand. Clients feedback proved the advantages of this kind of shale shaker: high G-force, wide screen area, compressed structure, cost-effective, etc. Nowadays we mainly provide both third generation linear motion shale shaker and fourth generation balanced elliptical shale shaker.


    Key Charateristics of Our Mud Shale Shaker:

    • Martin or OLI vibration motor.
    • Vibration strength is 7.5G, adjustable.
    • Hopper type feed mode reduces feed speed.
    • Screen box angle is mechanical and adjustable.
    • Wedge-type compaction device facilitates fast replacement of screen.
    • Schneider or Siemens electrical components.
    • Overall heat treatment, long time work.

    Parameters of TR Drilling Shale Shaker


    ModelTRPS703TRPS585-4TRZS703TRZS585
    Vibration MotionBalanced Elliptical MotionLinear Motion
    Treatment Capacity130m³/h140m³/h120m³/h130m³/h
    Motor Power1.94+1.0kw1.94+1.0kw1.5KW×21.72KW×2
    Screen Specs.(700×1250mm)×3(585×1165mm)×4(700×1250mm)×3(585×1165mm)×4
    Screen Area2.6m²2.7m²2.6m²2.7m²
    Vibration Strength≤7.1G≤7.1G≤7.1G≤7.1G
    Double Amplitude7mm7mm6mm6mm
    Deck Adjustment-1°~+5°-1°~+5°-1°~+5°-1°~+5°
    Ex StandardExdIIBt4 / IECEX / A-TEX
    Weight1630kg1618kg1620kg1600kg
    Dimension2770×1785×1690mm2966×1600×1280mm2770×1785×1690mm2966×1600×1280mm
    RemarkAbove data are tested from the drilling mud with viscosity 45s,and specific gravity 1.2g/cm3.


    Application


    Our drilling shale shaker is currently used in trenchless HDD, Drilling Waste Management, oil & gas drilling, city bored piling, tunneling construction, micro-tunneling, environment protection, mining, Oil Sludge Dewatering Systems, Oil Mud Seperation, Coal Bed Gas Solids Control System, Water Drilling etc.


    Competitive Advantages


    1. We offer high quality products at competitive price.
    2. Shortest delivery time.
    3. Flexible payment terms.
    4. Timely after-sale service.
    5. Most of our equipment can be replaceable with international brands.
    6. Our products have been exported to Argentina, Egypt, US, Australia, Romania, Pakistan, Dubai, Abu Dhabi, Iran, India, Indonesia, Vietnam, Malaysia and many other countries.


    Company Tenet


    Customer's satisfaction is the highest pursuit of TR Solids Control.
