    Horizontal Centrifugal Mud Pump HDD / Oilfield Drilling 13 Inch Impeller Diameter

    Ask Lasest Price
    Brand Name : TR Solids Control
    Model Number : TRSB5*4-13J
    Certification : API Certificate, ISO Certified
    Price : Negotiable
    Payment Terms : T/T, L/C, D/A, D/P, Western Union
    Supply Ability : 10000 Pcs / Month
    Delivery Time : 15 days after receiving 30% deposit
    • Product Details
    • Company Profile

    Horizontal Centrifugal Mud Pump HDD / Oilfield Drilling 13 Inch Impeller Diameter

    HDD / Oilfield Drilling Solids Control Horizontal Centrifugal Sand Pump


    Mian Introduction


    Centrifugal sand pump is used to provide drilling liquid with a certain discharge capacity and pressure to desander,desilter and mud pump. The centrifugal pump developed by TR Solids Control through over more than ten years of site applications and improvements is in the domestic advanced level, either in technical performance or in sealing life, and reaches the same level as the similar products abroad.


    Our TRSB series sand pump has been designed and developed for petroleum drill in solid control equipment. It adopts the axial sucking structure and all the hydraulic components are friction proof cast iron, which is suitable for delivering the corrosive liquids with suspended particles in well drilling or other similar liquids.


    Key Benefits of Our Centrifugal Pump:

    1. No block: open impeller design.
    2. High efficiency: impeller and pump casing flow path adopt the best leisure design.
    3. Long life: impeller and pump casing flow path are optimized for streamline design.
    4. Beautiful appearance: overall structure is vertical with small floor area.
    5. Mechanical seals are made of hard alloys and their service life is 5 times that of ordinary seals.
    6. No leakage: composite seals with main mechanical seals and auxiliary packing seals.

    Main Specifications of TR Drilling Centrifugal Pump


    ModelPowerFlowLift(m)EfficiencyNPSHElectric
    TRSB8×6-14J75KW320m3/h40m65%550HZ
    TRSB8×6-12J355m3/h43m66%4.860HZ
    TRSB8×6-13J55KW290m3/h33m64%5.550HZ
    TRSB6×5-12J196m3/h48m61%360HZ
    TRSB6×5-13J45KW180m3/h34m60%350HZ
    TRSB5×4-14J149m3/h61m58%4.660HZ
    TRSB6×5-12J37KW160m3/h30m60%350HZ
    TRSB5×4-12J112m3/h45m58%4.660HZ
    TRSB6×5-11J30KW120m3/h21m62%2.550HZ
    TRSB5×4-12J112m3/h37m57%4.660HZ
    TRSB5×4-12J22KW90m3/h30m56%4.550HZ
    TRSB5×4-10J105m3/h30m57%4.260HZ
    TRSB5x4-11J18.5KW90m3/h24m56%4.550HZ
    TRSB4x3-12J55m3/h46m48%460HZ
    TRSB4x3-13J15KW50m3/h40m48%4.550HZ
    TRSB4x3-11J54m3/h35m47%460HZ
    TRSB4x3-12J11KW45m3/h30m47%450HZ
    TRSB3x2-12J28m3/h45m40%3.160HZ
    TRSB3x2-12J7.5KW45m3/h24m46%450HZ
    TRSB3x2-11J25m3/h35m41%3.160HZ
    TRSB3x2-11J5.5KW20m3/h23m39%350HZ


    How To Choose Centrifugal Pump?


    • Mudflow: According to whole mud system flow rate or mud pump flow.
    • Type: Vertical type or horizontal type.
    • Motor: 50Hz or 60Hz, motor speed.
    • Application: Mixing pump or feed pump.

    Competitive Advantages


    1. We offer high quality products at competitive price.
    2. Shortest delivery time.
    3. Flexible payment terms.
    4. Timely after-sale service.
    5. Most of our equipment can be replaceable with international brands.
    6. Our products have been exported to Argentina, Egypt, US, Australia, Romania, Pakistan, Dubai, Abu Dhabi, Iran, India, Indonesia, Vietnam, Malaysia and many other countries.


    Company Tenet
    Customer's satisfaction is the highest pursuit of TR Solids Control.
