    Oilfield Jet Mud Mixer 150mm Inlet Diameter For Drilling Mud In Solids Control System

    Ask Lasest Price
    Brand Name : TR Solids Control
    Model Number : TRSLH150-40
    Certification : API Certificate, ISO Certificate
    Price : Negotiable
    Payment Terms : T/T, L/C, D/A, D/P, Western Union
    Supply Ability : 5000 Sets Per Month
    Delivery Time : 15 days after deposit
    • Product Details
    • Company Profile

    Oilfield Jet Mud Mixer 150mm Inlet Diameter For Drilling Mud In Solids Control System

    Oilfield Jet Mud Mixer for Drilling Mud Used in Solids Control System


    Product Introduction


    Jet Mud Mixer is mainly used to weight the amount of drilling mud and changing drilling fluid density and viscosity, water lose, etc. If jet mud mixer works with shearing pump, the efficiency of it will increase rapidly. Double jet mud mixer can be also produced according to your requirements.


    Our jet mud mixer can be matched with other drilling solids control system. It’s safe and reliable, and easy to move. It can improve pressure head of mixed liquid, enhance dispersion effect of material, make the material recycle and mix enough in the mud tank.

    TRSL series mud hopper are welcomed by clients for good price and high performance. Also, we have short delivery and many models for you to choose from. Nowadays mud hopper is widely used in oil & gas drilling, horizontal directional drilling, tunnel & microtunnelling, shield construction, etc. Welcome your inquiry at any time! Jet Mud Mixer according to the user requirements.It is designed by solids control bentonite mud mixer,drilling mud tank jet mixer.


    Main Features of Our TR Jet Mud Mixer

    1. Double jet mud mixer can be also produced.
    2. If working with shearing pump, its efficiency is very high.
    3. HL Jet mud mixer consists of mechanical seal mixing pump and venturi hoppers.
    4. Can meet accentuation and preparation of drilling fluid in drilling solid control system between 1500m and 6000m.
    Specifications of TR Drilling Jet Mud Mixer

    ModelTRSLH150-50TRSLH150-40TRSLH150-30TRSLH100
    Matched PumpTRSB8×6-13J(55kw)TRSB6×5-13J(45kw)TRSB5×4-14J(37kw)TRSB4X3-11J(15kw)
    Capacity240m3/h180m3/h120m3/h60m3/h
    Work Pressure0.25~0.40Mpa0.25~0.40Mpa0.25~0.40Mpa0.25~0.40Mpa
    Inlet Diameter150mm150mm150mm100mm
    Nozzle Diameter50mm40mm30mm30mm
    Hopper Size750x750mm750x750mm600x600mm600x600mm
    Burden Speed≤100kg/min≤80kg/min≤60kg/min≤40kg/min
    Weight1600kg1450kg1300kg1100kg
    Dimension2200*1700*1200mm2200*1700*1200mm2000*1650*1100mm2000*1650*1100mm


    China manufacturer TR Solids Control offer the world with drilling mud jet mud mixer. We are an exporter of drilling fluid jet mud mixer for Indian, Russian,middle east.etc. We manufacture and design hydraulic bentonite mud mixer,drilling mud tank jet mixer.We supplied to Oilfield Company of the Turkey Venezuela, Indonesia, Russia, the United Arab Emirates,Turkey,and Morocco and Century Int'l Oilfield Equipments LLC of the United Arab Emirates etc. Choose us as supplier. Our factory and company are Quality Management System ISO 9001-2000 certified.


    Competitive Advantages


    1. We offer high quality products at competitive price.
    2. Shortest delivery time.
    3. Flexible payment terms.
    4. Timely after-sale service.
    5. Most of our equipment can be replaceable with international brands.
    6. Our products have been exported to Argentina, Egypt, US, Australia, Romania, Pakistan, Dubai, Abu Dhabi, Iran, India, Indonesia, Vietnam, Malaysia and many other countries.

    Company Tenet

    Customer's satisfaction is the highest pursuit of TR Solids Control.
