    API / ISO Certificated Mud System Energy Saving For Drilling Mud Treatment

    Ask Lasest Price
    Brand Name : TR Solids Control
    Model Number : TRZJ50
    Certification : API Q1, ISO 9001:2000
    Payment Terms : L/C, T/T, Western Union
    Price : Can be negotiated
    Supply Ability : 3000pcs per month
    Delivery Time : 30days
    • Product Details
    • Company Profile

    API / ISO Certificated Mud System Energy Saving For Drilling Mud Treatment

    API and ISO Certified Oil Drilling and Mud Cleaning Equipment Mud Recycling System

    Introduction

    Oil Drilling Mud System may contain shale shaker, Vacuum Degasser, Mud Desander, desilter, Mud Cleaner, Decanter Centrifuge, centrifugal pump, Drilling Mud Agitator, Mud Gun, Jet Mud Mixer, poor boy degasser, Mud Tank, etc. TR solids control system will suit rig max drilling depth from 2000m to 9000m, as well as the offshore rig or jack-up platform drilling. We promise clients optimal solution with a cost-efficient budget.

    TR oil & gas solids control system can be designed to meet different kinds of conditions in oil and gas drilling field. Our oil mud system ensures good and efficient treatment effects of removing solids particles and gas bubbles in oil and gas drilling fluids. We design and customized detailed technical drawing of the system according to clients' special requirements and drilling site application.

    Features of TR Oil Drilling Mud System

    1. Compact structure system for space limited area.
    2. Trailer mounted mud system for flexible utilizing need.
    3. Harmonious and functional mud tank layout for practical application.
    4. Energy saving efficiency is significant since the power consumption of the vibrating motor is low.
    5. The polyurethane screen has many advantages such as easy operation, low trouble rate, convenient installation and maintenance.
    6. Winterization frame and heating manifold installed with mud system to keep mud performance in extremely cold area.


    Main Specification of TR Oil Drilling Mud System

    Configure EquipmentZJ70ZJ50ZJ40ZJ30ZJ20ZJ10
    Mud Tank≥270m³/h≥200m³/h≥180m³/h≥160m³/h≥160m³/h≥80m³/h
    Storing Tank≥160m³/h≥120m³/h≥80m³/h≥80m³/h××
    Shale Shaker≥360m³/h≥280m³/h≥240m³/h≥180m³/h≥140m³/h≥80m³/h
    Vacuum Degasser360m³/h300m³/h240m³/h×
    Desander≥320m³/h≥240m³/h≥200m³/h≥180m³/h≥120m³/h
    Desilter≥320m³/h≥240m³/h≥200m³/h××
    Middle Speed Centrifuge50m³/h50m³/h40m³/h×
    High Speed Centrifuge40m³/h40m³/h×××
    Jet Mud Mixer≥300m³/h≥240m³/h≥200m³/h≥180m³/h≥120m³/h≥80m³/h
    Shear Pump≥120m³/h≥120m³/h≥120m³/h≥120m³/h≥100m³/h×
    Charging Pump≥240m³/h≥200m³/h≥180m³/h≥150m³/h≥100m³/h×



    API / ISO Certificated Mud Recycling System for Drilling Mud Treatment

    Competitive Advantages
    1. We offer high quality products at competitive price.
    2. Shortest delivery time.
    3. Flexible payment terms.
    4. Timely after-sale service.
    5. Most of our equipment can be replaceable with international brands.
    6. Our products have been exported to Argentina, Egypt, US, Australia, Romania, Pakistan, Dubai, Abu Dhabi, Iran, India, Indonesia, Vietnam, Malaysia and many other countries.


    Company Tenet
    Customer's satisfaction is the highest pursuit of TR Solids Control.
