Oilfield Equipment Vertical Mud Gas Separator / Poor Boy Degasser

Product Introduction

Mud gas separator is the first stage safety equipment in the modern drilling operations, designed to provide effective separation of the mud and gas circulated from the well by venting the gas and returning the mud to the tank.It is mainly used to remove the big bubbles with the diameter of ≥Φ3mm, most of which are the expanded gas filled in the drilling fluids.

TR Solids Control is a leader in mud gas separator. Our TRZYQ series mud gas separator is devided into normal pressure Mud gas separator and pressure auto-control Mud gas separator, according to the pressure. TR mud gas separator is a field proven and extremely reliable safety equipment designed for today’s challenging drilling operations. It is your best choice to prevent drilling mud invasion.

Main Advantages of TRZYQ Series Mud Gas Separator

1. Anti-corrosion epoxy coating to ensure long service life
2. Mainly used to clear away big bubbles of Φ3-Φ25mm.
3. Reducing hazardous gas threat: separated free gas is discharged by vent lines to a safe place for combustion
4. Separated free gas from drilling fluids, including toxic gases such as hydrogen sulfide
5. Adopting bottom-sealing structure. 6.Skid-Mounted 7.Simple structure,large disposal capacity,high degassing efficiency,convenient transportation/installation.

Technical Parameters of TRZYQ Series Mud Gas Separator

Product Application

Liquid gas separator is made of suction assembly, drain pipe assembly, ladder, pedestal and tank body assembly. Before used the separator put it on the smoothy earth and connect the suction pipe. The suction pipe connect used 5″national standard flange, one side of flange welding 5″ suction line connect the pump and connect the flange by bolt. Welding ″fuller unionat the export of exhaust pipe and welding it with 8″pipeline. Connect drain pipe with 8flange and welding the other side of this flange with 8 pipeline.

Our Mud Gas Separator is mainly used to remove the enormous free gas from drilling fluids, including poisonous gases like H2S. Currently it is widely used in Drilling Waste Management, city bored piling, trenchless HDD, oil & gas drilling, Coal Bed Gas Solids Control System, Oil Sludge Dewatering Systems, mining, Water Drilling, environment protection, Oil Mud Seperation etc.

Competitive Advantages

1. We offer high quality products at competitive price.
2. Shortest delivery time.
3. Flexible payment terms.
4. Timely after-sale service.
5. Most of our equipment can be replaceable with international brands.
6. Our products have been exported to Argentina, Egypt, US, Australia, Romania, Pakistan, Dubai, Abu Dhabi, Iran, India, Indonesia, Vietnam, Malaysia and many other countries.

Xi'An TianRui Petroleum Machinery Equipment Co.,Ltd. (For short: TR Solids Control) is a professional manufacturer of solids control equipment and mud recovery system, located in Xi'an City, China. Since 2010, TR Solids Control focused on the development and production of various types of solids control equipment & system. Our R&D personnel are composed of rich experienced crew who have long-time work on oil drilling mechanical design, so we supply professional drilling solids control equipment with the enterprise spirit of continuously improvement and constantly innovation.

Our main products include: drilling mud shale shaker, decanter centrifuge, mud agitator, mud cleaner, desander, desilter, vacuum degasser, submersible slurry pump, centrifugal pump, screw pump, shear pump, jet mud mixer, mud hopper, liquids gas separator, flare ignition device, mud tank. Spare parts like shaker screens, hydrocyclones, impeller, mechanical selas and gear box etc. They are widely used in oil and gas drilling, coal bed methane system, trenchless HDD & tunneling, micro-tunneling, drilling waste management, bored pile construction, etc.

TR Solids Control brings in international advanced technology and imports high precision processing equipment for production, and builds talent training cooperation relations with lots of university in Xi’An city for replenishing new blood continuously to us. We also formed a high-tech modern integrated enterprise with design, manufacture, sales and service. TR Solids Control has our own improved management system, high level professionals and excellent service team. Our production management strictly implements API quality specification requirements, and we have strict regulations to materials procurement, producing and processing , equipment debugging and whole process of equipment ex-factory. We’re fully capable of supplying satisfied products and services timely as per client’s request.

In terms of products quality management, TR Solids Control continuously update our own management level. We passed the international quality management system ISO9001-2015. TR Solids Control pursuits high-quality product and establishes excellent quality management system, this enables us to get the appraoval from clients.

TR Solids Control adheres to the enterprise purpose--Customers’ Satisfaction is the Highest Pursuit of us. Our goal is to create the global famous brand enterprise, and supply excellent and stable drilling fluids recycling purification system and HDD(Horizontal Direction Drilling) mud recycling system to users. Our products are used in Chanceful Oilfield in north of Shaaban, Chang Oilfield, Sinkiang Oilfield and other national drilling company. At the same time we exported our products to almost 40 countries and regions like South America, US, Europe, Egypt, Dubai, Abu Dhabi, Oman, Pakistan, Russia, Australia, Korea, Vietnam, Myanmar, etc.

Our goal is simple: to sell the best equipment at the best prices, and provides industry-leading customer service. We personally get to know each of our customers, and we know how to discover the most valuable part of our business is Perfect Solids Control Equipment, to help others achieve their goals.
